Supported Models

2005 – 2015 third-generation (NC series) 1.8 and 2.0-litre MX-5, Miata models worldwide.

• Supported by PhoneFlash
  1. All models can have their Engine ECU programmed via PhoneFlash. Click here to find out more about how you can program your MX-5 Miata NC with PhoneFlash




  2. RaceROM Custom Features

     RaceROM Custom features are written into our tuning software to give you unique features that don’t come as standard. They need to be set up by an EcuTek tuner, and you may be charged extra as they take time to configure.

     • Four-way Mode Switching
       • Swap between four different modes using ECU Connect or your cruise control switches if fitted. For example, Track Mode; Fast Road Mode, E85 Mode; Economy Mode. It’s up to you to decide what set-up you want in each mode.
     • Per-Gear Rev Limits
       • Set a different rev limit for each gear to help you achieve those vital drag times, one for each Map Switch mode
     • Closed-Loop Boost Control
       • Your tuner can safely set up closed-loop boost control using a boost control solenoid managed by the stock ECU. This also allows your tuner to set up per map switch mode, per gear boost control. This saves you buying a stand-alone boost controller.
     • Adjustable Launch Control
       • Live adjustment of the launch RPM using the cruise-control switchgear or the ECU Connect app.
     • Flat-foot Shift
       • Make full-throttle gearshifts by reducing engine torque and controlling the engine speed during the gear change.
     • Auto Blip
       • Applies a short burst of throttle when downshifting under braking to provide a smooth entry into the next gear
     • Self Adjusting FlexFuel
       • No more worries about calculating the ethanol in the tank; our RaceROM self-adjusting flex-fuel does it all for you. Just fit a CANbus enabled Flex Fuel sensor, and off you go. Whatever Ethanol content in the tank, the tune will automatically adjust to give you optimal performance. Link up with ECU Connect or use the Sports Display to display the current Ethanol blend. A quick check can be carried out when stationary just by pressing the cruise control button to sweep the tacho needle to display ethanol percentage up to 70%
     • 2 CANBus Inputs
       • Add a range of external sensor inputs. For example: Zeitronix ECA-2 ethanol sensor
       • Zeitronix ZT-3 wideband sensor
       • Innovate LC-3 multi-sensor
       • ECUmaster CANswitch
       • Autosport AnalogX
       • Custom user-defined CAN sensor
       • CAN devices such as the AnalogX allow for multiple variable inputs that can be used to import 0-5v sensors, driver trim switches or even a combination including a 0-5v ethanol content signal.
     • 2 CANBus Comms Outputs
       • If you add external controllers, such as the Motiv Motorsport RE|FLEX box, Meth’s kits, Nitrous kits, etc. you can export engine parameters to trigger specific actions.
